Avaya Scopia XT5000 User Manual

• The Avaya Scopia
®
XT7000 Series and the Avaya Scopia
®
XT5000 Series support stereo1
audio in point to point calls when an Avaya POD microphone is used. Stereo audio is only2
available if it is supported also by the remote party, when in a point to point SIP or H.323 call3
using AAC-LD, G.719 or OPUS audio codecs. When stereo is active, the additional POD4
microphone does not capture audio in the room, but it is available to mute/unmute the system.5
• High quality video and audio even with limited bandwidth or poor network conditions, by using6
these compression methods (in addition to standard H.263 and H.264). It requires both sides of7
the transmission (sending and receiving endpoints) to support this protocol.8
- H.264 Scalable Video Coding Technology (SVC) in point-to-point calls. SVC extends the H.9
264 codec standard to dramatically increase error resiliency and video quality without the10
need for higher bandwidth.11
- H.264 High Profile is a standard for compressing video by up to 25% over the H.26412
Baseline Profile, enabling high definition calls to be held over lower call speeds.13
- H.265 supersedes H.264 as a compression standard, allowing high quality calls with even14
lower bandwidth consumption (XT7000 Series only).15
- NetSense is a proprietary Equinox Solution technology which optimizes the video quality16
according to the available bandwidth to minimize packet loss. As the available bandwidth of17
a connection varies depending on data traffic, NetSense's sophisticated algorithm18
dynamically scans the video stream, and then reduces or improves the video resolution to19
maximize quality with the available bandwidth.20
• Ability to record videoconferences to a locally connected USB drive or the network and to save21
them to a generic remote server - which could be Equinox Streaming and Recording for22
content management and playback - using FTP/S (may require license, depending on the23
model).24
You can only directly record to the network if your Equinox Solution includes an Equinox25
Streaming and Recording server, the XT Series is managed by Equinox Management, and the26
meeting is hosted by a Equinox Media Server (or older model).27
• For an even better experience, Scopia
®
Control enables you to remotely control the XT Series28
features using the intuitive touch interface of an iOS device. It may require license, depending29
on the model.30
• Secure point-to-point video calls and videoconferences, via encrypted connections or using31
TLS. You can have up to three remote encrypted participants in a videoconference.32
Important:
Using encryption is subject to local regulation. In some countries it is restricted or limited33
for usage. For more information, consult your local reseller.34
Among the latest XT Series products are Avaya Scopia
®
XT7100 and Avaya Scopia
®
XT4300.35
The Avaya Scopia
®
XT7100 is the new generation Avaya flagship product in the Avaya Scopia
®
36
series of room systems. The XT7100 incorporates dual 1080p/60fps live video and content, HD37
audio, H.265, H.264 High Pofile and Scalable Video Coding (SVC), and nine sites multiparty calling.38
H.265 saves up to 50% bandwidth with respect to H.264 High Profile. Dual HDMI input allows39
December 2017 Avaya Scopia
®
XT Series User Guide 9
Avaya - Proprietary. Use pursuant to the terms of your signed agreement or Avaya policy.
DRAFT—December 15, 2017—1:33 PM (UTC)

Avaya Scopia XT5000 Specifications

General

Brand	Avaya
Model	Scopia XT5000
Category	Conference System
Language	English
