Page 36
2.9.1.5 Phase Rotation
Rectifier modules are not sensitive to phase rotation.
2.9.1.6 Phase Voltage
The Input Phase Voltage is detailed in Table 2–16.
Nominal voltage is a.c. r.m.s, 3 phase, 3-wire and earth/ground.
The equipment will operate with a variation of ±10% of the nominal supply voltage. For supply voltages below
the nominal, there will be a corresponding reduction in maximum output power. The equipment can operate
up to a maximum of +15% variation on the nominal supplies for a maximum of 30 cycles duration without the
equipment tripping though reduced performance may be observed.
Supply frequency : 45 Hz to 63 Hz.
Input AC Voltage
Output DC Link Voltage
Module
Nominal AC Input
Voltage (V r.m.s.)
Maximum
Output
(V d.c.)
Maximum Allowed
Regenerative Voltage
(V d.c.)
MVRL2100-4601/2
575 - 690
1122
1250
Table 2–16. – Input a.c. Voltage & Output d.c. Link Voltage Ratings
