5-pin terminal block connector port
• De-embedded audio, extracts balanced 2-channel analog PCM audio
3.5mm stereo jack (TRS) audio input port
• Auto-detects input once directly connected, will override HDMI input audio
USB 2.0 Type B female connector port
• USB extension for connecting to a computer or other USB 2.0 devices
• Supports KVM routing and hosting
Recessed button, use a paperclip or pen to press in and hold for 7 seconds to
restore encoder to factory default settings
DC 12V/1A locking ring power charger to locally power encoder
• Not required when connecting encoder to a network switch that provides PoE
