1. FIRST INSTALLATION RECOMMENDATIONS
POWER SUPPLY
The apparatus is equipped with 2 standard XLR 4-pin connectors, namely primary and secondary, to facilitate
a redundant power supply setup. It is worth noting that the second external power supply is OPTIONAL.
The primary external power supply unit and its cable of approx. 1.8 mt. lengths are supplied with the device,
and the type of the power supply cable plug is a Hybrid CEE 7/7 plug (compatible with E and F socket types).
If for any reason, you need to use this appliance with a different plug, you should use the following wiring
guidelines in replacing the existing plug with the new one:
Green, or green and yellow
Neutral (N) Blue
Supply cables should be laid in such a manner that one does not step or walk on them. They should
not be squashed by any objects.
POWER SUPPLY
The device is designed for operation with an external power supply of 100 to 240 VAC, and 50 Hz to 60 Hz.
Check the corresponding device labeling for compatibility with the domestic line voltage and frequency
before connecting the IEC power connector to the main supply!
WARNING
Disconnect the mains power plug before you open
the housing. Repair of the equipment must only be
carried out by authorized and qualified personnel.
