MENU | AUDIO
TONE GEN.
OXYGEN Digital Console comes with a built-in audio tone generator. The tone range is 30 Hz - 20 kHz and
you can select it by following these steps: -
MENU: MAIN / AUDIO / INPUTS / TONE GEN.
This option is too useful for tuning instruments, science experiments, and testing audio equipment (how
low does my subwoofer go?).
4.1.3. OUTPUTS
OXYGEN Digital console is coming with variant audio output connectors like XLR, JACK, USB, and RJ45 to
give you maximum flexibility with your instruments and your project cabling. With all those functions you
can save time and money. As well as the creative USB connection and Dante technology, we don’t need a
sound card or a professional instrument to connect any media player or recorder like a PC, Workstation, or
laptop.
OXYGEN outputs included:
2 Stereo XLR Male - Balanced Audio Connection (47Ω).
2 Stereo RJ45 Female audio and GPIO connections.
1 Telco I/O RJ45 Female audio and GPIO connections.
1 Analog Telephone Line - RJ11 - PSTN Interface
1 AES/EBU Stereo XLR Male - Balanced Digital Connection (110Ω).
32 Stereo RJ45 Female DANTE audio.
2 USB Audio Card USB -Type B - PC Connections.
1 Stereo Output - Jack 6.3mm - Unbalanced Audio Connection (nominal 32Ω).
