56
MENU | AUDIO
USB AUDIO
2 USB audio interface per each board
The USB audio interface allows you to directly connect the PC to the Oxygen console, with no need for audio
cards. in fact, the PC detects the console as a digital audio card with 2 stereo inputs and 2 stereo outputs for
simultaneous playout and recording (Bidirectional).
two Built-in stereos USB I/O Audio Interface to connect directly to a computer. USB Audio Card with a
connector Type-B. With this type of connection, you can save hundreds of dollars on an audio card. By
OXYGEN Digital Mixing Console, you can connect your computer or any digital device via perfect USB audio
I/O sources.
Once the mixer is connected to a computer, it will be recognized automatically and will not require any
intervention. The connection is made via a normal USB-B cable 2.0
NOTE: Highly recommend that not use a (SS 10)
SUPERSPEED USB port on the PC side.
To set the parameters correctly, set the input/recording and output/playback as default (48000 Hz).
