MENU | AUDIO
TB MIC:
OFF: the microphone is not a Talkback mic. This selection can disable the microphone to disconnect
it from the talkback connection.
From CR to ST: talk with the Studio using this microphone.
From ST to CR: talk with the Control Room via this microphone.
ON MODULE:
from here can select how to but in ON the microphones connected to TalkBox, you can choose between
FADER & BUTTON, BY FADER, BY BUTTON, ALWAYS ON, and ALWAYS OFF.
ADV. SETTINGS
EQ:
Parametric EQ: This type of EQ allows you to select a specific frequency to be adjusted with the
FREQUENCY knob and adjust the bandwidth of the EQ with the Q knob. The Gain knob allows you to
boost or cut the selected frequency.
When adjusting the bandwidth of the EQ, you can choose between a "Peak" or "Shelving" filter. A Peak filter
allows you to adjust the bandwidth of a specific frequency range, while a Shelving filter adjusts the
bandwidth of all frequencies above or below a certain point.
These are graphic equalizers that offer a versatile adjustable wide band ranging the spectrum from 22.4 Hz
to 20 kHz. This equalizer enables the sound to be amplified or reduced in specific frequency bands, which
allows for the manipulation of the quality and characteristics of the sound. Furthermore, a maximum boost
or cut can be applied to the LOW-CUT and HI-CUT frequencies.
To activate or deactivate the EQ for the chosen source, simply press the Equalizer button. To manipulate
the 5 frequency bands (LOW CUT, BASS, BASS-MID, MID, MID-HIGH, HIGH, and HI-CUT), navigate to
MENU / AUDIO / INPUTS / MIC / MIC 1 / ADV. SETTINGS / EQ
Press the menu button (
«
) or (
»
) to switch between the pages of EQ types that are available.
Select the specific frequency to be adjusted with the FREQUENCY knob, and adjust the bandwidth of the EQ
with the knob, also you can choose between PEAK or SHELVING of BASS and HIGH.
Finally, boost or cut the selected frequency with the Gain knob.
After confirming any editing, you will see clearly the change that you do in the graphic equalizer display with
different color signals, as well as it is effective at the input source quality and character.
