MENU | AUDIO
MODE: This function has been added to prevent unauthorized people from activating or deactivating the
equalizer.
UNLOCKED: that is mean the equalizer is free and can activate or deactivate the equalizer from the F button
on the surface.
LOCKED ON: that is mean the equalizer of this channel will be still ON and cannot turn off from the F button.
LOCKED OFF: that is mean the equalizer of this channel will be still OFF and cannot turn ON from the F
button.
EQ PRESET: This function is useful to save and recall the equalizer settings. These settings are saved in the
internal memory and it is not exportable.
SNAPSHOT: it’s able to save ten different EQ PRESET by selecting the position of the new save from 1 to 10
before saving it.
NAME: here is can change the name of the PRESET to identify them.
RECALL: to recall one of the PRESETs that are already saved in internal memory.
SAVE: to save the actual equalizer setting as a PRESET.
LOWCUT: This is an audio frequency filter that cuts out all of the low sounds below a certain frequency.
On the OXYGEN console, you are given knobs to control the frequency of the low cut in a full range from
22.4Hz to 20.0KHz. Also, you can control how gradual or steep the cut is. Doing so will eliminate the
amplification of unwanted low sound. unwanted sound can be:
Microphone handling or floor rumble (from bumping the mic or stepping on the floor that the mic
stand is sitting on).
The popping of “P’s” and “B’s” from a voice.
Unwanted electrical hum (60hz).
When you activate the LOWCUT function and confirmed it, that change will appear immediately at the
output sources, and it will be shown in the EQ graphic display as well the LOWCUT mark ( [ ) will change to
yellow color.
HIGH CUT: This is an audio frequency filter that cuts out all of the frequency above which the source
signals a certain frequency. manipulates the reflection density in the simulated room.
