MENU | SNAPSHOT
4.2. SNAPSHOT
This function is useful to save and recall the settings. These settings are saved in the internal memory and
it is not exportable. [MORE INFO ]
SNAPSHOT: it’s able to save ten different PRESETS by selecting the position of the new save from 1 to 10
before saving it.
NAME: here is can change the name of the PRESET to identify them.
RECALL: to recall one of the PRESETs that are already saved in internal memory.
SAVE: to save the actual setting as a PRESET.
4.3. GENERAL SET.
4.3.1. GPIO
Here we will talk about only the physical GPIO connections. You can find the GPIO over IP in the TELCO
part. [MORE INFO ]
The full version of OXYGEN comes with two SUB-D 9pin (female DE-09) as a connector of general-purpose
input/output (GPIO). Each one of these two connectors is equipped with two programmable GPI and two
programmable GPO.
