1640-IN-031-C-08 Page 29 of 104
MACO Series Controller Installation
Eurotherm/Barber-Colman
Bond to
Chassis
Zone 1 T/C -
Zone 1 T/C +
Zone ...
Zone ...
Chassis
(Shielded T/C Cable)
Pin 18
Pin 17
Pin 18 bonded to EMC bond rail at factory
Figure 2.5 Wiring T/C Inputs using the T/C-Analog Card
Bond to
Chassis
Bond to
Chassis
Zone 1 ( -)
Zone 1 (+)
Zone ...
Zone ...
Chassis
(Braided Shield)
(Braided Shield and Overbraid)
Pin 18
Pin 17
Pin 18 bonded to EMC bond rail at factory
Figure 2.6 Wiring Analog Inputs using the T/C-Analog Card
