1640-IN-031-C-08
Page 40 of 104
Eurotherm/Barber-Colman
MACO Series Controller Installation
Figure 5.3 Wiring the Analog I/O Board
Bond to
Chassis
Bond to
Chassis
Do NOT connect
shields at this end
(Braided Shield)
(Braided Shield and Overbraid)
