Barber-Colman MACO Series User Manual

1640-IN-031-C-08 Page 49 of 104
MACO Series Controller Installation
Eurotherm/Barber-Colman
PARISON PCB
Input 1+
Input 1-
Output 1+
Output 1-
EX+
EX+
EX-
EX-
Analog In 1 Plus (+)
Analog In 1 Minus (-)
Analog Out 1 (+)
Excitation 1 (+)
Analog Common 1 (-)
Cal 1 A
Cal 1 B
A-13441 SERVO AMP
P15
Servo Assembly #1
LVDT
Excitation
Input
Servo Control
Input
LVDT
Position
Output
Analog In 3 Plus (+)
Analog In 3 Minus (-)
Analog Out 3 (+)
Excitation 3 (+)
Analog Common 3 (-)
Cal 3 A
Cal 3 B
P17
Position Detection
Position
Output
500 Ω
to
2k Ω
EX+
Valve or Valve Amplifier
(for Pushout Control)
Figure 6.7 Two-Head Position-Based Machine with Pushout and B-C Servo Amp
