1640-IN-031-C-08 Page 85 of 104
MACO Series Controller Installation
Eurotherm/Barber-Colman
Figure 13.3 Wiring the DC Input Board
DC Common
DC In 1
DC In 2
DC In 3
DC In ...
DC Common
Note that NO Shield or Overbraid is necessary.
