Barber-Colman MACO Series User Manual

1640-IN-031-C-08 Page 47 of 104
MACO Series Controller Installation
Eurotherm/Barber-Colman
Figure 6.5 Two-Head Time-Based Machine with B-C Servo Amp
PARISON PCB
Input 1+
Input 1-
Output 1+
Output 1-
EX+
EX+
EX-
EX-
Analog In 1 Plus (+)
Analog In 1 Minus (-)
Analog Out 1 (+)
Excitation 1 (+)
Analog Common 1 (-)
Cal 1 A
Cal 1 B
A-13441 SERVO AMP
P15
Servo Assembly #1
LVDT
Excitation
Input
Servo Control
Input
LVDT
Position
Output
Input 2+
Input 2-
Output 2+
Output 2-
Analog In 2 Plus (+)
Analog In 2 Minus (-)
Analog Out 2 (+)
Excitation 2 (+)
Analog Common 2 (-)
Cal 2 A
Cal 2 B
P16
Servo Assembly #2
LVDT
Excitation
Input
Servo Control
Input
LVDT
Position
Output
