1640-IN-031-C-08 Page 53 of 104
MACO Series Controller Installation
Eurotherm/Barber-Colman
Figure 6.12 Wiring the High Speed Analog Signal Processor (Parison) Board Analog Inputs
Figure 6.13 Wiring the High Speed Analog Signal Processor (Parison) Board Analog Outputs
Bond to
Chassis
Bond to
Chassis
Connect Input minus to Analog
Common at the sensor
Ana In +
Ana In -
Ana Common
(Braided Shield)
(Braided Shield and Overbraid)
Bond to
Chassis
Bond to
Chassis
Ana Out+
Ana Common
(Braided Shield)
(Braided Shield and Overbraid)
