1640-IN-031-C-08 Page 95 of 104
MACO Series Controller Installation
Eurotherm/Barber-Colman
DB9 Connector Kit, Female
9 Pin Female D Connector
Jack Screws (2)
9 Pin Connector Housing
71-761
19-16-352
50-1628
E24-1147
DB25 Connector Kit, Female
25 Pin Female D Connector
Jack Screws (2)
25 Pin Connector Housing
71-762
E24-175
50-1628
E24-1148
9 Conductor RS-232 Cable
(Belden Type 9539)
E26-210
Cables:
RS-232 Communications
RS-485 Communications
or
Operator Station to Data Handler
46-24
3 Conductor Cable
(Alpha Type 1737)
DB25 Connector Kit, Male
25 Pin Male D Connector
Jack Screws (2)
25 Pin Connector Housing
71-776
E24-22
50-1628
E24-1148
4 Conductor RS-232 Cable
(Belden Type 9534)
E26-106RS-232 to Black Box Serial to Parallel Converter
Note that all E24-1134-XXX Mating Connectors, as well as E24-1129 (on the Analog I/O Board)
are capable of 14 to 22 AWG wire.
For ease of wiring, use 18 AWG where loads permit. In any case, wire sizes must be large
enough to meet any code requirements that apply.
For supply connections, use No. 18 AWG or larger wires rated for at least 75°C (167°F).
Class 2 wiring must be separated a minimum of 1/4 inch from any Class 1 conductors.
Figure 17. Communications Cable Part Numbers
