Barber-Colman MACO Series User Manual

1640-IN-031-C-08 Page 35 of 104
MACO Series Controller Installation
Eurotherm/Barber-Colman
ISO Com
Data -
Data +
N/C
Bond to
Chassis
Overbraid in Conduit
to Operator Station
(Braided Shield)
ISO Com
Data -
Data +
N/C
Bond to
Chassis
Overbraid to
Operator Station
(Braided Shield)
Figure 4.1 Wiring the Data Handler Board (Overbraid in Conduit to Op Station)
Figure 4.2 Wiring the Data Handler Board (Overbraid to Op Station)
