About this chapter
Most installation, maintenance and service procedures demand removing one or more of the projector covers
to gain access to the parts to maintain or to service. To avoid redundancy, all procedures about cover
removing or installing are grouped together in this chapter. The maintenance and servicing procedures also
refer to this chapter if required. The procedures in this chapter describe, with detailed step by step actions and
illustrations, how to remove or install the projector covers. Note that the covers may only be removed by
qualified service personnel.
WARNING: All procedures described in this chapter may only be performed by TRAINED
PROJECTIONISTS or qualified SERVICE PERSONNEL.
WARNING: Always switch off the projector and unplug the power cord before removing one of the
covers, unless otherwise stated.
Overview
•
Removal of the front cover
• Removal of the rear cover
• Removal of the top cover
• Removal of the left side cover
• Removal of the right side cover
• Removal of the top cover plate of the Light Processor compartment
• Removal of the side cover plate of the Light Processor compartment
• Installation of the side cover plate of the Light Processor compartment
• Installation of the top cover plate of the Light Processor compartment
• Installation of the right side cover
• Installation of the left side cover
• Installation of the top cover
• Installation of the rear cover
• Installation of the front cover
R5906790 /04 Athena
Removal and
installation of the
projector covers
16
