R5906790 /04 Athena46
7.1 Introduction
General
The Input & Communication side of the Athena consists of a Local Keypad integrated into the projector
housing and a card cage with three slots. The top side of the projector is equipped with a tail light which
reflects the status of the projector.
The projector card cage is equipped with an ICMP(-X). See illustration below. Note that all information about
the ICMP(-X) is gathered into one separated chapter: “ICMP(-X)”, page 59.
Image 7-1
1 Projector status light.
2 Power ON/OFF switch.
3 Local keypad.
4 Barco Cinema Controller.
5 ICMP(-X).
CAUTION: A unit may only be removed from the card cage by qualified service personnel.
Removing one of the boards (except for the Cinema Controller) will result in an authorization
request upon starting.
7.2 Local Keypad
Identification of the buttons
DOWSER
1 4
2 5
3 6
ZOOM
FOCUS
SHIFT
21 3 4 5 6 7
8 9 10 11 12
Image 7-2
Input & Communication
