R5906790 /04 Athena 21
The power cord required to connect the projector with the power net is not delivered with the projector. It is the
responsibility of the customer to provide the correct type of power cord. The cross-sectional area of the
conductors in the power supply cord shall not be less than 1mm
2
(16AWG), minimum 300V.
To protect operating personnel, the National Electrical Manufacturers Association (NEMA) recommends that
the instrument panel and cabinet be grounded. In no event shall this projector be operated without an
adequate cabinet ground connection.
The AC supply must be installed by a qualified electrician in conformance to local codes. Hardware, wire sizes
and conduit types must comply with local codes.
A readily accessible disconnect device shall be incorporated externally to the equipment for removal of the
power.
UPS requirements
The Uninterruptible Power Supply (UPS), also known as a Continuous Power Supply (CPS), must have an
output voltage of 200-240V at 50-60Hz and must be capable of delivering an output power of 250W. This UPS
provides only power for the electronics and lamp cooling, but not for the lamp.
The connection between the UPS unit and the UPS inlet of the projector must be done with a certified AC
power supply cord of minimum 0,75 mm² or 18 AWG and minimum 300V.
WARNING: Disconnect the power cord for removal of all power from the unit.
The Athena does not have a built in UPS unit.
Projector weight
Do not underestimate the weight of the Athena. The projector weights approximately 53 kg (116.8 lb.) without
lens. Ensure that the pedestal on which the projector is installed is capable of supporting the complete load of
the system. Minimum 4 adult persons are needed to carry the projector.
Barco offers a pedestal for the Athena projector. This universal pedestal allows for a solid and easy
setup of the projector. The universal pedestal support 19” rack systems. (projector peripherals such
as alternative content switchers, ShowVault, etc.)
3.2 Unpacking the projector
What you need to do?
Upon delivery, your projector is packed into a carton box upon a wooden/plastic pallet and secured with
banding and fastening clips. Furthermore, to provide protection during transportation, the projector is
surrounded by foam. Once the projector has arrived at the installation site, it needs to be removed from its
carton box and wooden/plastic pallet in a safe manner without damaging the projector.
How to unpack your projector?
1. Loosen the banding (1) by pulling the free end of the banding loop in the clip.
