Barco DP2K-6E User Manual

R5906790 /04 Athena140
1
1
Image 16-3
2. Remove the top cover from the projector.
16.4 Removal of the left side cover
WARNING: Switch off the projector prior to starting with this procedure, unless otherwise specified
in the procedure.
The back and front cover must be removed before the left side cover can be removed. This
procedure assumes that the back and front cover are already removed.
Required tools
3 mm Allen Key (Hex key)
How to remove the left side cover?
1. Loosen and remove the three screws at front of the projector (reference 1, Image 16-4) and the three screws
at the back of the projector (reference 1, Image 16-5). Use a 3 mm Allen Key.
Removal and installation of the projector covers

Barco DP2K-6E Specifications

General

Contrast ratio (typical)	1600:1
Projector native resolution	2K (2048x1080)
Ethernet LAN	Yes
Ethernet LAN (RJ-45) ports	3
Noise level	48 dB
AC input voltage	200 - 240 V
