Barco DP2K-6E User Manual

R5906790 /04 Athena 47
Functionality of the buttons
1
Numeric buttons (No.1 - 6)
All the Numeric buttons (reference 1 Image 7-2) of the Local Keypad have a white backlight during
normal operation. When the authorization process is activated with the (security) Key button, the
backlight color of the Numeric buttons changes to yellow. Each button can be linked to a macro which
allows you to setup the projector to your requirements with one push of a button.
2
Marker area
Each Numeric button has a marker area (reference 2 Image 7-2) where you can write down the name of
the Macro.
3
Standby button
Standby button (reference 3 Image 7-2) switches the lamp and lamp electronics immediately ON or OFF.
The lamp cooling fans remain active for about 5 minutes. The backlight color of the Standby button
remains white in standby mode and changes to green in operation mode.
4
Dowser button
The Dowser button (reference 4 Image 7-2) opens or closes the electronic dowser. The backlight color of
the Dowser button is green when the dowser is open and white when the dowser is closed.
5
Test Pattern button
The Test Pattern button (reference 5 Image 7-2) gives direct access to a limited set of the internal test
patterns of the projector. This is a toggle button. To exit the Test Pattern mode toggle through all test
patterns. Note that the convergence test pattern is not included in this set. The backlight color of the Test
Pattern button is green if one of the test patterns is activated and white if none is activated.
6
Focus button
The Focus button (reference 6 Image 7-2) allows you to focus the projected image on the screen. The
backlight color of the Focus button is red in case the end of range is reached.
7
Shift button
The Shift button (reference 7 Image 7-2) allows you to shift the lens up/down or left/right. The backlight
color of the Shift button is red in case the end of range is reached.
8
Sleep button
Pushing the Sleep button (reference 8 Image 7-2) for 3 seconds puts the projector in Sleep mode
(energy saving). In case the projector is processing the after cooling cycle then the projector goes in
Sleep mode after finishing the after cooling cycle. The backlight color of the Sleep button is purple during
after cooling and white in Sleep mode.
Push the Sleep button for 3 seconds in Sleep mode to awake the projector (put in Standby). The
backlight color of the Sleep button in Standby mode is green.
Enter or leave Sleep mode can also be done via a 2 dedicated projector command (USB/Ethernet), or
via two predefined Macros (not editable) with GPIO, or via the Communicator.
The Sleep button is disabled if the lamp is on.
9
Star button
Star button (reference 9 Image 7-2). Pressing the Star button a few seconds will activate the ICMP reset
process.
10
Key button
The (security) Key button (reference 10 Image 7-2) is used for the authorization procedure to clear
tamper errors etc. (service purposes). Pin codes can be added/changed with the Communicator.
11
Zoom button
The Zoom button (reference 11 Image 7-2) allows you to zoom in or out the projected image on the
screen. The backlight color of the Zoom button is red in case the end of range is reached.
