Status overview
Depending on the condition of the projector the status light may have 4 colors: Green, Yellow, Red or Blue.
Each color represent a different state:
Blinking Green Projector is booting up. (Fully booted up when Test Pattern button is white as well)
Green Projector is running normally.
Yellow Projector is running with warnings. Event can go on but a technical intervention will be necessary in the near future
to prevent a complete stop of the projector.
Red Projector is in error state. Problem could prevent normal operation. Solve the problem before continuing with the
projector.
Blue Projector runs in notification state. Maintenance action required. Lamp run time is exceeded. New lamp must be
installed.
Standby mode
In Standby mode the lamp of the projector is switched OFF but all the electronics of the projector remain fully
operational. The projector is ready to ignite the lamp and project the image. The status light is not different
between Standby mode and Lamp ON mode (fully operational).
Sleep mode
If the projector is in Sleep mode then the status light flashes every ten seconds. The color of the flash
depends on the state of the projector. In other words, the color of the flash will be green in normal state (no
warnings, no errors, no notifications).
In Sleep mode the total power consumption of the projector is less than 15W. No fans are turning and the
Lamp Power Supply (LPS) is switched OFF completely. Only the following functionalities of the projector
remains active:
• Cinema Controller
• Local Keypad
• Router and external switch fully functional
• USB IN port type “B” (Virtual comport RS232)
• USB OUT port type “A” (To power handheld devices [500mA MAX]. No other functionality supported)
• GPIO port on the Cinema Controller
Pressing the Sleep button in Standby mode for 3 seconds puts the projector in Sleep mode. In case the
projector is processing the after cooling cycle then the projector goes in Sleep mode after finishing the after
cooling cycle.
Pressing the Sleep button in Sleep mode for 3 seconds will awake the projector. The status light will blink for a
few seconds (booting up all inactive boards) and then lights up continuously.
Enter or leave Sleep mode can also be done via 2 dedicated projector command (USB/Ethernet), or via two
predefined Macros (not editable) with GPIO of the Cinema Controller (not the GPIO of the ICMP(-X)), or via
the Communicator.
The projector always boots up in the same mode (E.g. Standby or Sleep) as it was switched OFF.
The Sleep button is disabled if the lamp is ignited.
