R5906790 /04 Athena96
7
Image 9-9
3. Move the Touch Panel interface to the desired position.
4. Fasten the central swivel clamp by turning the knob clockwise.
CAUTION: Never release the central swivel lock without supporting the Touch Panel interface.
Communicator Touch Panel
