Instruction Manual w VERTICUS 5 Compressor Units
F-5
Connection data for three-phase motors
Operating voltage 230 V Operating voltage 400 V/500 V
Drive
motor
power
in kW
Nomi
nal
motor
current
in A
Fuse values for
start-up in A
Mains cable
wire gauge in
mm
2
from
Drive
motor
power
in kW
Nomi
nal
motor
current
in A
Fuse values for
start-up in A
Mains cable
wire gauge in
mm
2
from
direct
star/
delta
Mains
to relay
Y/ to
motor
direct
star/
delta
mains
to relay
Y/ to
motor
1,1 4,6 6 1,5 1,5 1,1 2,6 4 1,5 1,5
1,5 6,3 16 1,5 1,5 1,5 3,6 6 1,5 1,5
2,2 8,7 20 1,5 1,5 2,2 5 10 1,5 1,5
3 11,5 20 2,5 1,5 3 6,6 16 2,5 1,5
4 14,8 25 20 2,5 1,5 4 8,5 20 16 2,5 1,5
5,5 19,6 35 25 4 2,5 5,5 11,3 25 16/20 2,5 1,5
7,5 26,4 50 35 6 4 7,5 15,2 25 20 2,5 1,5
11 38 63 50 6 4 11 21,7 35 25 4 2,5
15 51 80 63 10 4 15 29,9 50 35 6 4
18,5 63 100 80 16 6 18,5 36 63 50 6 4
22 71 100 80 16 6 22 41 63 50 10 4
30 96 160 125 25 10 30 55 80 63 10 6
37 117 200 160 35 16 37 68 100 80 16 6
45 141 250 160 50 16 45 81 125 100 25 10
55 173 300 200 70 25 55 99 160 125 25 16
75 233 355 300 95 35 75 134 200 160 35 25
90 279 425 355 120 50 90 161 224 200 50 25
110 342 500 400 110 196 250 224 70 35
132 401 630 500 132 231 300 250 95 50
160 486 630 630 160 279 355 300 120 70
Notes:
1. This table contains approximate values without
obligation and is applicable for BAUER units, only.
2. The values are based on the current standards DIN VDE
0100 and 0113, and on standard rules
3. For units without starter relay (direct starting) use the
wire gauges in the “mains to relay” column for connection
from mains to motor.
