11.4. COMPRESSOR CONTROLLER B-CONTROL II
(optional extra for all Verticus 5 com
pressor units)
The electric control is placed in the control room at the right
side of the compressor building.
The unit is only allowed to operate
with the switch cabinet doors
closed!
For schematic diagrams refer to section F.
The values indicated in the following de
scription are merely samples from one of
many different configuration possibilit
ies. Therefore, the values indicated on the
compressor unit may be different from
the ones shown here.
11.4.1. Description
The BAUER B-Control is a free-programmable electronic
compressor control system. Communication with the user
takes place via a modern LCD touchscreen display and 10
touch keys. The control system is specially designed for
BAUER compressors.
Fig. 38 B-Control control panel and display
