Instruction Manual w VERTICUS 5 Compressor Units
A-27
Technical data
Tank capacity: approx. 60 litres
Condensate capacity: approx. 40 litres
Activated charcoal contents: 3,700 g
Connecting hose length: 1,150 mm
Dimensions: approx. 410 mm x 330 mm
x 1,000 mm (W x D x H)
10.8. CONDENSATE DISPOSAL
Condensate must be disposed of accord
ing to applicable regulations (in Ger
many: special waste disposal no. 54405).
Due care must be taken to ensure that any oil which may
be drained with the condensate will not pollute the envir
onment. For example, the drain pipe can be directed into
a collecting vessel or into drain facilities incorporating oil
separators.
10.9. ELECTRICAL CONNECTION
For electrical connection of the automatic condensate
drain system refer to the schematic diagrams in section F,
if applicable.
On compressor units with B-CONTROL
compressor control system the intervals
are adjusted at the control and monito
ring unit, refer to chapter A-11.
