TECHNICAL DATA (Cont.)
13.1.4. Filter systems
a. General
Service pressure, standard 225/330/420 bar (3,200/4,500/6,000 psi)
Service pressure, max. 420 bar (6,000 psi)
Flow rate P61: max. 600 l/min
P81: max. 1,000 l/min
Regenerated volume of air, referenced to 1 bar abs, 20C,
flow rate 200 l/min against p = 200 bar (2,900 psi)
P61: 2,200 m
3
; (1,700 m
3
with CO cartridge)
P81: 4,400 m
3
Operating temperature range +5 ... +50C (41 ... 122F)
Residual water contents < 10 mg/m
3
Residual oil vapour contents < 0.1 mg/m
3
Residual CO contents < 5 ppm
V
Residual CO
2
contents < 500 ppm
V
Pressure dew point -20 C, 3 mg/m
3
at 300 bar
b. High pressure filter assemblies
Oil and water separator:
220/330 bar units (3,100/4,500 psi) 420 bar units (6,000 psi)
External diameter 95 mm 95 mm
Length 306 mm 306 mm
Water volume 0.54 l 0.54 l
Weight 9 kg 9 kg
Tube connections (intake and outlet) G 1/4” G 1/4”
Max. load cycle number refer to chapter D.5. refer to chapter D.5.
Purifier:
220/330 bar units (3,100/4,500 psi) 420 bar units (6,000 psi)
External diameter 100 mm 115 mm
Length 835 mm 835 mm
Water volume 2.85 l 2.85 l
Weight 10,6 kg 14 kg
Tube connections (intake and outlet) G 3/8” G 3/8”
c. Filter cartridges for filter system P61 and P81
BAUER part no. Cartridge contents
a)
SECURUS
sensor
Length
mm
Capacity MS (g)
a)
Capacity AC (g)
a)
058825 MS --- 705 1445 ---
058826 MS/MS/AC/MS --- 695 1275 113
060036 MS/MS/AC/MS  705 1224 113
060037 MS/MS/AC/MS/HP  705 1002 115
a) MS = Molecular sieve, AC = Activated charcoal, HP = Hopcalite
