Product Description QTERM-G55 Terminal
32
Qlarity-Based Terminal Hardware
3.1.1 Specifications
The following tables contain the technical specifications for the QTERM-G55.
TERMINAL DISPLAY
Grayscale (standard) FSTN 16 shades of gray
Active Matrix Color (optional) TFT 256 colors
Pixels 320 x 240
Dot Pitch
FSTN 0.24 mm
TFT 0.227 mm
FSTN Contrast Software-controlled, temperature compensated
Lighting Light emitting diode brightness is software-controllable
Backlight Brightness
FSTN 10 nits typical
TFT 200 nits typical
KEYPAD
24- or 40-keys
Steel snap domes in membrane
Lighted keypad with electroluminescent lighting (optional)
Optional emergency stop switch (2-pole, normally closed)
INTERFACE
Standard EIA-232 serial port with hardware or software handshaking
Baud rates 600 – 115,200 bps
Flow control
None
XonXoff (software)
RTS/CTS (hardware)
Data formats
7 or 8 data bits
1 or 2 stop bits
Even, odd, or no parity
(PC Tools support only 8 data bits)
Connector
Handheld - 12-pin round (Hirose HR30-8R-12SC)
Integral cable with DB15f
Panel-mount - DB9f (2 with optional second serial port)
8-pin modular (RJ45) with Ethernet option
Options
Primary serial port configurable as EIA-232, EIA-422, or EIA-485
Secondary serial port available (EIA-232, EIA-422, or EIA-485)
Ethernet 10Base-T with support for TCP/IP networking
Power-over-Ethernet
