3.2.1.7.1 Power Interface with E-stop Option and Integral Cable
The following table shows the pinout for each type of power interface when the E-stop option
and integral cable are selected.
3.2.1.7.2 Serial or Network Interface with E-stop Option and Integral Cable
The following table shows the pinout for each type of serial or network interface.
3.2.1.7.3 E-stop Switch Interface with Integral Cable
The following table shows the pinout for the two-pole normally closed E-stop switch when the
integral cable option is selected. The conductors for each pole (Pole 1 and Pole 2) of the switch
are shorted until the switch is activated. After activation, each pole is an open circuit until the
switch is reset.
3.2.1.8 Integral Cable Wire Color Code
The following table shows the wire color code for the DB15f connector on the integral cable;
this information is provided to facilitate removal of the DB15f if desired. Six of the fifteen
conductors in the cable are wired as 100 ohm twisted pairs, as shown in the table. One of the
fifteen conductors is a non-insulated drain wire which is shorted to the foil shielding in the
cable.
DB15f Pin
Regulated
(standard)
5 Volt Unregulated Power-over-Ethernet
9 8 - 32 VDC 4.5 - 5.5 VDC No connect
1 Ground Ground Ground
11 No connect No connect PoE V+
5 No connect No connect PoE V-
DB15f Pin EIA-232 EIA-422 EIA-485
Ethernet
(including PoE)
7Tx Tx+ RTx+ Tx+
14 RTS (out) Tx- RTx- Tx-
6 Rx Rx+ No connect Rx+
13 CTS (in) Rx- No connect Rx-
DB15f Pin E-stop Switch
4Pole 1
12 Pole 1
8Pole 2
15 Pole 2
