QTERM-G56 Terminal Powering On the Terminal for the First Time
Qlarity-Based Terminal Hardware 61
4.3.7 Applying Power
Power is supplied to the QTERM-G56 terminal via the 12-pin round connector or integral
cable. DC power must be in the range of 8 to 32 volts (the current will vary depending on the
input voltage; see the following table).
4.4 Powering On the Terminal for the First Time
When you connect power to the QTERM-G56 terminal, the unit will remain unpowered until
you press the power button on the keypad. The unit is turned on or off by pressing the power
button. When the unit is powered on, it automatically loads the application saved in flash
memory into RAM memory and executes the application. If no application is present, the
Application Loader banner should appear on the display.
When you power on the terminal for the first time, a demo application (or a special application
custom designed for your company) automatically loads. The demo application will help you
verify that the terminal is operating properly. Follow the on-screen prompts or any documenta-
tion accompanying the program to guide you through tests or demonstrations designed to ver-
ify terminal operation.
Once you have verified that the terminal is functioning properly, refer to Chapter 8, “Power On
Setup” for information on configuring your terminal. The Power On Setup utility includes
functions to do the following:
• Change orientation of the terminal display (portrait or landscape)
• Download a new user application to the terminal
CAUTION
QTERM-G56 power must come from an SELV (Safety Extra Low Voltage) power source
and should have a current limit on its output of 5 Amperes. It must provide a minimum of 8
volts DC power and be limited to a maximum of 32 volts DC. Limiting may be inherent to
the supply or may be provided by supplementary overcurrent devices. If the QTERM-G56
does not respond or exhibits abnormal behavior on power up, disconnect power and contact
Beijer Electronics for technical support.
Current Consumption
Terminal 12 VDC 24 VDC
Power off 2 mA 5 mA
Idle 75 mA 50 mA
Ethernet option, active 155 mA 90 mA
Ethernet option, idle 130 mA 80 mA
Active 200 mA 115 mA
EL Keypad Backlight add 10 mA add 6 mA
