4.2.1.1 Power and USB Device Interfaces
The following table shows the pinout for the power and USB device interfaces.
4.2.1.2 Serial Multiprotocol Port Interface
The following table shows the connector pinout for the selected type of serial interface on the
multiprotocol port.
4.2.1.3 Additional Serial Interface (without Ethernet option)
The following table shows the connector pinout for the G56L EIA-232 serial interface.
4.2.1.4 Network Interface (with Ethernet option)
The following table shows the cable pinout for the 10/100Base-T network interface.
Pin
Regulated
(standard)
PC USB
Host Port
1 8 - 32 VDC 4.5 - 5.5 VDC
2 Ground Ground
11 N/A USB D+
12 N/A USB D-
Pin EIA-232 EIA-422 EIA-485
3 Tx Tx- RTx-
4 RTS (out) Tx+ RTx+
5 Rx Rx+ No signal
6 CTS (in) Rx- No signal
Pin EIA-232
7Tx
8RTS (out)
9Rx
10 CTS (in)
Pin Ethernet
7Tx+
8Tx-
9Rx+
10 Rx-
