Product Description QTERM-Z60 Terminal
74
Qlarity-Based Terminal Hardware
Lighting Cold-cathode fluorescent, brightness is software-controllable
Backlight Brightness 200 nits typical
TOUCH SCREEN
Analog-resistive operation
Transparent touch area over viewable display
Labeled touch underlay area on each side of display
INTERFACE
Z60/H EIA-232, -422 or -485 serial port
Z60/L EIA-232 serial port
Baud rates 600 – 115,200 bps
Data formats
7 or 8 data bits
1 or 2 stop bits
Even, odd, or no parity
(PC Tools supports only 8 data bits)
Connector Molex 43045-1218
Mating Connector Molex 43025-1200
Mating Connector Pins Molex 43030-0001
MEMORY
Standard 2 Mbytes flash and 16 Mbytes SDRAM
SPEAKER
Standard Software programmable pitch and duration
PHYSICAL
Configuration Panel-mount
Housing
Glass-filled polyester, UL 94V-0 flame rating, accommodates panels
from 0 to 7 mm thick with standard screws
Size 215 x 161 x 50 mm
Weight 0.98 kg
Processor ARM 720T 77 MHz
ENVIRONMENTAL
QTERM-Z60/H Sealing NEMA-4 front panel
QTERM-Z60/L Sealing NEMA-12/13 front panel
Temperature
Operating: 0 to 50
°C
Storage: -10 to 60 °C
Humidity 0 to 95%, non-condensing
TERMINAL DISPLAY
