Field Description
Possible values are &, , , and 3 (standard
value)
• For Operation Band = @F /- and @F
- and @F -
Only the 3 option is possible here.
Selected Channel Displays the channel used.
Used Secondary Chan-
nel
Not for Operation Mode = 3%% and Operation
Band = @F /-
Displays the second channel used.
Bandwidth Only for Wireless Mode = "/#/, #/,
, /
Select how many channels are to be used.
Possible values:
• '@F (default value): One channel with 20 MHz bandwidth
is used.
• '@F: Two channels each with 20 MHz bandwidth are
used. In the case one channel acts as a control channels and
the other as an expansion channel.
Number of Spatial
Streams
Only for Wireless Mode = "/#/, #/,
, /
Select how many traffic flows are to be used in parallel.
Possible values:
• &: Three traffic flows are used.
• : Two traffic flows are used.
• : One traffic flow is used.
Transmit Power Select the maximum value for the radiated antenna power. The
actually radiated antenna power may be lower than the maxim-
um value set, depending on the data rate transmitted. The max-
imum value for Transmit Power is country-dependent.
bintec elmeg GmbH
10 Wireless LAN
bintec RS Series 177
