Field Description
Possible values:
• 311 (default value): The filter is valid for all port numbers
• +%$( +: Enables the entry of a port number.
• +%$( + #: Enables the entry of a range of port
numbers.
Source IP Address/
Netmask
Enter the source IP address and netmask of the data packets.
Source Port/Range
Only if Protocol = *6, .5
Enter a source port number or the range of source port num-
bers.
Possible values:
• 311 (default value): The filter is valid for all port numbers
• +%$( +: Enables the entry of a port number.
• +%$( + #: Enables the entry of a range of port
numbers.
DSCP/TOS Filter
(Layer 3)
Select the Type of Service (TOS).
Possible values:
• # (default value): The type of service is ignored.
• 56 ;( 91: Differentiated Services Code Point
according to RFC 3260 is used to signal the priority of IP
packets (indicated in binary format, 6 bit).
• 56 5%1 91: Differentiated Services Code Point
according to RFC 3260 is used to signal the priority of IP
packets (indicated in decimal format).
• 56 @?%1 91: Differentiated Services Code
Point according to RFC 3260 is used to signal the priority of
IP packets (indicated in hexadecimal format).
• *- ;( 91: The TOS value is specified in binary
format, e.g. 00111111.
• *- 5%1 91: The TOS value is specified in decimal
format, e.g. 63.
• *- @?%1 91: The TOS value is specified in
hexadecimal format, e.g. 3F.
