S10/S12/S10A/S12A Patient Monitor User’s Manual
17-9
17.2.8.1. Entering the Full Disclosure Review Page
Choose one of the following methods to enter the Full Disclosure review page:
Select【Review】quick keySelect【Full Disclosure】submenu.
Select【Main Menu】quick keyform 【Review】 column select 【Full
Disclosure】.
17.2.8.2. Selecting Compressed waveforms
To review compressed waveforms, you must first select which parameters to store
and display. Follow these steps:
1. Enter the Full Disclosure review page.
2. Select 【Setup】 submenu to enter 【Full Disclosure Setup】 page.
3. Select 【Storage】 submenu and select the desired waveforms to be stored.
4. Select 【Display (Maximum: 3)】 submenu and select the desired waveform
to be displayed from the stored waveforms.
CAUTION:
If more waveforms are selected in the 【Storage】 column, the storage time of
these waveforms will be shortened due to the limitation of memory size. The
waveforms may not be stored for 72 hours. Please exert caution when selecting
waveforms.
When an alarm occurs, the band on the compressed waveform at the alarm time
will use different shading to indicate different alarm levels.
Red: high priority alarm
Yellow: med priority alarm
Cyan: low alarm priority
17.2.8.3. Setting Gain and Duration
To set the length of time each compressed waveform is displayed and the ECG
