S10/S12/S10A/S12A Patient Monitor User’s Manual
19-7
19.5.1. Calculation Step
The oxygenation calculation steps are as follows:
1. Access oxygenation calculation page by either of the following ways:
Select【Calculations】quick key【Oxygenation】submenu.
Select【Main Menu】quick keyfrom 【Calculations】 column to
select 【Oxygenation】.
2. Enter the correct value for each parameter. For a patient who is being
monitored, the currently measured values are automatically taken, and the
height and weight are derived from the patient information entered.
3. Select 【Calculate】 to calculate the value of each output parameter. The
calculated value is greater than the normal upper limit is indicated by an up
arrow “”; the calculated value is lower than the normal lower limit is
indicated by a down arrow “”.
In the Oxygenation page, you can also perform the following operations:
Select 【Oxygen Unit】, 【Hb Unit】 and 【Pressure Unit】, then
corresponding parameter values will be automatically converted and
updated accordingly.
Select 【Range】 to show the normal range of each parameter.
Select 【Unit】 to show the unit of each parameter.
19.5.2. Input Parameters
Input Parameter Unit Full Name
C.O. L/min cardiac output
FiO2 bpm percentage fraction of inspired oxygen
PaO2 mmHg, kPa partial pressure of oxygen in the arteries
PaCO2 mmHg, kPa partial pressure of carbon dioxide in the arteries
SaO2 % arterial oxygen saturation
