S10/S12/S10A/S12A Patient Monitor User’s Manual
5
A.5.3 Mainframe LED
Alarm lamp
Cyan, yellow and red
Power indicating lamp
1 (Green/Orange)
When powered with AC, it lights green while turn on and off
the monitor.
When powered with battery, the orange light is on when the
battery is turned on, and no light is on when the battery is
turned off.
Battery charging
indicating lamp
1 (yellow), When charging, it is always on, and when it is fully
charged, the light goes out.
A.5.4 Audio indicating
Speaker
Give alarm tone (45-85dB), QRS tones;
Support PITCH TONE and multi-level tone modulation;
Alarm tones meet the requirements of IEC 60601-1-8.
A.5.5 Input device
Keys
Physical keys 1 power switch key
Touch screen support
Others
Mouse input Support (optional)
Keyboard input Support (optional)
Barcode scanner Support (optional)
Voice assistant Support (optional)
A.5.6 Connectors
Power
1 AC power inlet with cable retainer
Wired network
1 standard RJ45 interfaces
USB
2 standard USB 2.0 sockets
