S10/S12/S10A/S12A Patient Monitor User’s Manual
6
VGA
1 standard VGA connector (optional)
Equipotential grounding
point
1
Multifunctional (nurse
call, defibrillation
synchronization and
analog output) interface
1 (optional)
A.5.7 Signal Output
Auxiliary output interface (optional)
Standard
Meet the requirements of IEC 60601-1 for short-circuit
protection and leakage current.
Output impedance Rated 50
ECG analog signals output
Output signal range
-10V～+10V
Maximum
transmission delay
25 ms
Sensitivity 1V/mV±5%
PACE rejection /
strengthen
Has PACE rejection function
IBP analog signals output
Output signal range
-1V～+4V
Maximum
transmission delay
35 ms
Sensitivity 1V/100mHg±5%
Nurse call output
Output voltage range High level: 3.5~5V, providing a maximum of 10 mA output
current;
Low level: ＜0.5V, receiving a maximum of 5 mA input
current.
