S10/S12/S10A/S12A Patient Monitor User’s Manual
10
Pacing pulse display
method in auxiliary
output
Suppression
Pacing function
switch
Pace markers function can be switched on and off.
Defibrillation output
delay
25ms
ECG Analog Output
Delay
25ms
A.8.1.3 ECG Measurement
Lead type
3-lead: I, II, III
5-lead: I, II, III, aVR, aVL, aVF, V-
6-lead: I, II, III, aVR, aVL, aVF,Va, Vb
12-lead: I, II, III, aVR, aVL, aVF,V1~V6
Auto: identify leads automatically
Indication of lead-off shall
be provided
Every electrode
ECG abnormal work
indications
Every amplification channel shall have an indication of
abnormal ECG operation (polarization).
Bandwidth (-3dB)
Diagnostic mode: 0.05~150Hz
Monitor mode: 0.5~40Hz
Operation mode: 1~25Hz
ST mode: 0.05~40Hz
Signal quality display
Expression way: numerical display and waveform color.
Defibrillation Protection
Breakdown Voltage: 4000V 50Hz/60Hz
Anti-defibrillation effect protection: baseline recovery
time: 5s (after defibrillation).
Input signal range
Input signal range -10.0mV~+10.0mV
Electrode offset
potential
±500 mV d.c.
