S10/S12/S10A/S12A Patient Monitor User’s Manual
12
sensitivity
ST Display
Display 12-lead ST segment values at the same time and support
ST graphic display.
ST measurement
range and accuracy
Measurement
range
-2.0mV~2.0mV
Resolution ±0.01mV
Accuracy
-0.8mV~0.8mV: ±0.02mV or ±10%,
whichever is greater
Other: Unspecified
ST Update period
10s
PVCs measurement
Indicates the number of PVC in the past minute, ranging from
0/min ~150/min.
Arrhythmia analysis
type
27 (see Table 2)
QT analysis function
Measurement
range
QT: 200ms~700ms
QTc: 200ms~700ms
deltaQTc: -500ms~500ms
QT-HR:
Adult: 15bpm~150bpm
Pediatric / neonatal: 15bpm~180bpm
Resolution
QT: 1ms
QTc: 1ms
Accuracy QT: ±30ms
Sampling rate
1000Hz (The time bias among every channels 100us)
Amplitude
quantisation
1 uV/LSB
Table 2 Arrhythmia Events list
No. Full Name Prompt information
1 Asystole Asystole
2 Ventricular Fibrillation/ Vent Fib/Tach
