S10/S12/S10A/S12A Patient Monitor User’s Manual
14
A.8.2 RESP
A.8.2.1 Measurement specification
Measurement
parameter
RR and respiration waveform
Source
RA-LA, RA-LL (default)
Excitation waveform
64 kHz
Error: ±10%
Excitation current
0.3mA RMS
Respiration Apnea
Alarm
Fixed high priority alarm
Adjustable delay time: 10~60s, error ±3s or ±10%
Cardiac interference
alert
Fixed high priority alarm
RR measurement
range and accuracy
Measurement range 0~150 rpm
Resolution 1 rpm
Accuracy ±2 rpm or ±2%, whichever is greater.
Bandwidth
0.2 Hz ~2.5Hz
Sweep speed
6.25mm/s, 12.5mm/s, 25mm/s, 50mm/s, ±10%
Baseline impedance
range
200~2500 (using defibrillator proof cable with resistance of
1k)
Measuring impedance
range
0.3~3
Gain
×0.25, ×0.5, ×1, ×2, ×4
A.8.3 NIBP
A.8.3.1 Standard
Meet standard of IEC80601-2-30
