121
A I. TECHNICAL SPECIFICATIONS
PLEASE NOTE
The manufacturer accepts no liability for damage caused by incorrect use of the apparatus.
GENERAL SPECIFICATIONS
Automatic random and continual access analyzer aimed at giving results per patient, with direct photometric reading
over a reactions rotor.
Preparation cycle time 24 s (up to 150 prep/h)
Warm-up time 25 mins
Reading time for each preparation Every 24 s, up to 10 mins
Dimensions 840 x 670 x 615 mm (33.1”x26.8”x24.2”)
(length x depth x height)
Weight 45 kg (100lb)
REAGENTS AND SAMPLES TRAY
Positions for racks 4
Capacity of the sample racks 24
Maximum number of samples 72
ø13 mm, ø15 mm sample tubes (max. height 100 mm), ø13 mm paediatric well
Capacity of the reagent racks 10
Maximum number of reagents 30
20 ml and 50 ml reagent bottles
Possible congurations
Sample racks Reagent racks Number of samples Number of reagents
1 3 24 30
2 2 48 20
3 1 72 10
DISPENSING SYSTEM
NEEDLE
Detachable tip
Vertical length 110 mm
Capacity level detection
Self-adjustment of position
NEEDLE THERMOSTATATION SYSTEM
Actuator Resistive elements
Control PID
Thermostatation time < 15 s
Dispensation temperature 37°C
Trueness ± 0.5°C
Repeatability ± 0.5°C
