biosystems A15 - Lighting System

Service manual
26
2.2.3.2. Lighting system
(1) BODY
(2) LAMP HOLDER
(3) HALOGEN LAMP
(4) LAMP HOLDER FASTENING
(5) FILTER WHEEL
(6) FILTER HOLDER
(7) FILTER HOLDER NUT
(8) MATCHED INTERFERENTIAL FILTERS
(9) WHEEL AXLE
(10) HOME PHOTODETECTOR
(11) FILTER MOTOR
(12) DIAPHRAGM
(13) FILTER WHEEL WINDOW COVER
(14) FILTER WHEEL
(15) GAP
3
6
5
4
7
10
13
15
18
21
