2.2.1.1. X Guide.
(1)
UPPER X T
OOTHED
AXIS
(2)
LOWER X
AXIS
(3)
X ST
AR
T PHOT
OSENSOR
(4)
BEARING X
AXIS
(5)
X MOTOR
(6)
X ST
AR
T PHOT
OSENSOR T
AB
(7)
AXIS SUPPORTS
This consists of two
supports (7) that hold the steel
axes (1 and 2) on
which the X carriage moves.
The photosensor
(3) indicates
the start position
of the
X carriage movement.
The motor X
(5) is
moved by a
rack (2).
The X carriage is
supported by the second axis (2) by means of a bearing (4).
1
3
6
4
5
2
7
1
2
3
4
5
6
14
16
