Service manual
48
The labeled connector COM2 is the auxiliar connector.
This connector is used to communicate with a second serial port in the computer. The function of this cable is to mo-
nitor the internal states of the analyser.
To show all this information, the user should execute the program: windows HyperTerminal and congure with the
following parameters:
Programa: Inicio\Todos los programas\accesorios\comunicaciones\hyperterminal
Baud Rate: 38400
Número de bits: 8
Stop bits: 1
Paridad: none
Onces is congured and connected the cable, switch on the analyser. In this moment will appear in the HyperTerminal
screen information about the analysers mode and the different executes states. In the initializate mode, the analyser
do an internal checking for each element, if someone has any error then in the screen will show the element that fails.
The following lines shows an exemple of the instructions during an initialization, (this information could change with
the improvements of the rmware) :
BIOSYSTEMS A15
Firmware initialization
Firmware Version: A15 User V3.12
Serial Number: 831050311
FLASH functions transferred to RAM
Interrupt Vectors transferred to RAM
Interrupts enabled
Checking rmware integrity
Checking program checksum:
Checksum correct! Program Checksum=0x5039 Size=427100
Checking A15 conguration checksum:
Checksum correct! Conguration Checksum=0x179C Size=856
Checking A15 conguration backup checksum:
Checksum correct! Conguration backup Checksum=0x179C
Size=856
Loading A15 Conguration from FLASH
Conguration in FLASH is correct
Adjustments loaded:
Temperature correction for Rotor=0.50
Temperature correction for Probe=0.00
System Liquid Detection=30
Waste Detection=29
Sensitivity of level detection=110
Origin X=60
Origin Y=280
Origin Z=430
Tray Reference X=675
Tray Reference Y=10
Washing station X=360
Washing station Y=5
Washing station Z=450
Washing station Ext X=360
Washing station Ext Y=95
Washing station Ext Z=540
Reactions Rotor X=110
Reactions Rotor Y=1044
Reactions Rotor Z=600
Rotor Distance between the dispensation point and the optic
system=610
Rotor Position correction regard to the dispensation point=98
Rotor Position correction regard to the optic system=-4
Filters Wheel correction=0
Filters and their Integration Times:
Filter 1=000 Integration Time= 20ms ( 40) Reference Time=
0ms ( 0)
Filter 2=340 Integration Time=205ms (400) Reference Time=
0ms ( 0)
Filter 3=405 Integration Time= 51ms (100) Reference Time=
0ms ( 0)
Filter 4=505 Integration Time= 51ms (100) Reference Time=
0ms ( 0)
Filter 5=535 Integration Time= 51ms (100) Reference Time=
0ms ( 0)
Filter 6=560 Integration Time= 51ms (100) Reference Time=
0ms ( 0)
Filter 7=600 Integration Time= 51ms (100) Reference Time=
0ms ( 0)
Filter 8=635 Integration Time= 51ms (100) Reference Time=
0ms ( 0)
Filter 9=670 Integration Time= 51ms (100) Reference Time=
0ms ( 0)
Filter 10=000 Integration Time= 20ms ( 40) Reference Time=
0ms ( 0)
TI/LB Hystoric:
F[01]: 00000000 00000000 00000000 00000000 00000000 00000000
00000000 00000000 00000000 00000000
F[02]: 00000000 00000000 00000000 00000000 00000000 00000000
00000000 00000000 00000000 00000000
F[03]: 00000000 00000000 00000000 00000000 00000000 00000000
00000000 00000000 00000000 00000000
F[04]: 00000000 00000000 00000000 00000000 00000000 00000000
00000000 00000000 00000000 00000000
F[05]: 00000000 00000000 00000000 00000000 00000000 00000000
00000000 00000000 00000000 00000000
F[06]: 00000000 00000000 00000000 00000000 00000000 00000000
00000000 00000000 00000000 00000000
F[07]: 00000000 00000000 00000000 00000000 00000000 00000000
00000000 00000000 00000000 00000000
F[08]: 00000000 00000000 00000000 00000000 00000000 00000000
00000000 00000000 00000000 00000000
F[09]: 00000000 00000000 00000000 00000000 00000000 00000000
00000000 00000000 00000000 00000000
F[10]: 00000000 00000000 00000000 00000000 00000000 00000000
00000000 00000000 00000000 00000000
F[01]: 000 000 000 000 000 000 000 000 000 000
F[02]: 000 000 000 000 000 000 000 000 000 000
F[03]: 000 000 000 000 000 000 000 000 000 000
F[04]: 000 000 000 000 000 000 000 000 000 000
F[05]: 000 000 000 000 000 000 000 000 000 000
F[06]: 000 000 000 000 000 000 000 000 000 000
