biosystems A15 User Manual

Service manual
50
149 128 111 111 107 113 119 145
154 126 113 110 108 111 119 144
155 128 115 111 110 113 124 145
161 130 114 112 110 115 125 148
161 133 117 112 112 116 125 154
169 140 123 121 118 122 133 161
190 155 134 133 128 134 146 176
Reactivos:
Rack 1 2 3 4
163 151 152 183
156 141 143 174
152 138 140 173
150 134 137 172
154 135 138 176
156 139 143 181
160 138 145 187
166 145 149 194
173 150 156 204
194 172 173 228
Initializating Motors
- Axis Z in HOME
- Axis Y in HOME
- Axis X in HOME
- ROTOR in HOME
- FILTERS WHEEL in HOME
- CERAMIC PUMP in HOME
Motors Initializated
Optics Initialization
- Filter correction=0
- Rotor correction=98 Rotor Lect. correction=-4
- Used wells:0
- Check DDC112..OK (FPGA 8Mhz Clock: OFF)
- DDC112 test: OK! (Result => 0046387)
Optics Initializated
Generating Pattern: 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0
Generating Gate: 0 0 0 0 1 1 1 1 0 0 0 0 0 0 0 1 1 0 0 0
OK
Z Axis Initialization
- Axis Z in HOME
Z Axis initializated
Penc:111111111000000000| OK
Z Axis Initialization
- Axis Z in HOME
Z Axis initializated
Probe AA
- X:X=Xcal+-1“
- Y:Y=Ycal+0“
AAEnd
Peltier Cells and Drivers Test
- Probe Peltier Driver Test: Ok! (Not implemented)
- Rotor Peltiers Driver Test: Ok!
Hardware Initializated
There are a few keys that work with the Hyperterminal,
to press some keys the analyser give information about
some element, the following keys has the function:
H: Help, help, shows the help text
R: Rotor Temperature, shows the rotor temperature
P: Probe Temperature, shows the needle temperatare
S: Level Scales, shows the scales mesures in %
A: Last A25 Stress Results
L: Actual Sensibility of Level Detection
N: Activate additional information of level detection (only
internal use)
K: Deactivate the power supply
B: Activate the buzzer
b: Deactivate the buzzer
E: Generate an encoder error (only internal use)
I: Activate the encoder interrupt (only internal use)
1: Increase the lter wheel position
2: Decrease the lter wheel position
9: Mesure the whole rotor, step by step
G: Once nish a work list, push the G and send to the
hyperteminal more detailed information of the work list
managemnet
D: Show the mesure depending on the number of key
pressed
1st press: activate the internal test DDC112,
always show the same count number
2nd press: activate the normal mesure DDC112,
show the count number mesured
3th press: stop the DDC112 mesure
+: Increase the integration time in 0.5ms
-: Decrease the intergration tie in 0.5ms
