Maintenance Instruction manual GSP
60 / 92 38107010002 en-US
Product fences for tomatoes and other products
Pull the product fences one after the
other towards the operator as far as they
will go and then remove from the leading
axle, moving them towards the right.
Fig.80: Product fences for tomatoes and other
products
Blade cover
Hold the blade cover at the handle with
your right hand.
Loosen the catch behind the blade guard
ring with the left hand und remove the
blade cover.
Fig.81: Blade cover
Load platter GSP H W, GSP HD W, GSP H Flex
Pull load platter towards operator until
guide bolts come loose from the holes of
the lateral support and remove.
Fig.82: Load platter
