3 Introduction
This document describes the possibilities and the properties of the EM-ABS-01 exten-
sion module for the frequency inverters of the ACU series of devices.
Note:
his document exclusively describes the
EM-ABS-01 extension module. It is not to be understood as fundamental
information for the operation of the frequency inverters of the ACU series
of devices.
The EM-ABS-01 extension module is an optional hardware component to extend the
functionality of the frequency inverter. It enables the data exchange within the net-
work and between the components which have been directly connected, for example
control and regulation elements.
n absolute value encoder or a SinCos encoder and an external DC 24 V power source
can be connected to the extension module EM-ABS-01. The connected volta
e source
can power the encoder. To that end, the encoder power supply must be set to “Via
X410A” via a parameter (Parameter
Power Supply 1186, see chapter 8.4.3 Power
supply). The voltage level for encoder power supply can be set via a parameter (Pa-
rameter
Supply voltage 1187, see Chapter 8.4.4 “Supply voltage”). The volta
e value
can be controlled via a measuring cable (often referred to as “sense” cable).
The EM-ABS-01 extension module extends the functionality of the frequency inverters
of the ACU series of devices by the following functions:
− System bus CAN
(Can interface ISO -DIS 11898, CAN High Speed, max. 1 MBaud).
See chapter 7 “System bus”.
− Analog input
DC -10…+10 V or DC 0…+
10 V.
See chapter 8.1 “Analog input EM S1INA”.
− Encoder interface including
PTC evaluation via HD-Sub-D female connector.
Supported encoder types:
o SinCos (optionally with commutation tracks for synchronous motors)
o EnDat 2.1 (encoder type with SinCos track required)
o Hiperface
o Being prepared: SSI encoder (optionally with TTL [RS-422]- or SinCos
track)
See chapter 8.4 “Encoder input EM”.
− Three digital inputs.
See chapt
er 8.3 “Digital inputs EM-SxIND
”.
− Two digital outputs, can
also be used as repetition fre
quency output.
See chapter 8.2 “Digital outputs EM-S1OUTD and EM-S2OUTD”.
− Adjustable voltage ou
tput for encoder supply.
See chapter 8.4.3 “Power supply” and 8.4.4 “Supply voltage”.
− DC 24 V voltage input for connecti
on of external power supply. Via this input a
connected encoder can be powered.
See chapter 5.3.3 “Power supply” 8.4.3 “Power supply”.
Note: Dependin
on the motor and encoder type used there are restrictions as
to usability in applications. See chapter 3.2 “Range of applications of en-
coders”.
Note: The EM-ABS-01 extension module has been enclosed with the frequenc
inverter as a separate component and must be fitted by the user. This is
described in the chapter 5.2 “Mechanical Installation”.
