BONFIGLIOLI Active Cube User Manual

84 EM-ABS-01 for ACU 03/12
8 Control inputs and outputs
8.1 Analog input EM S1INA
8.1.1 General
The analog input of the EM-ABS-01 extension module can be used as a volta
g
e input.
Parameterization of the input signal is done via the definition of a linear characteristic
and assignment as
− Reference value source
(selectable via parameter 󳮁
Reference frequency source 475),
− Reference percentage source
(selectable via parameter 󳮁
Reference percentage source 476),
− Actual percentage source
(selectable via parameter 󳮁
Actual percentage source 478, in configuration x11)
or
− limit value sources
(can be selected via the parameters 734 … 737).
8.1.2 Characteristic
Mapping of the analog input signal onto a reference frequency value or a reference
percentage value is possible for various requirements. Parameterization is to be done
via two points of the linear characteristic of the reference value channel.
T
he characteristic point 1, with the coordinates X1 and Y1, and the characteristic poin
t
2, with the coordinates X2 and Y2, can be set in four parameters.
Points X1 and X2 are stated in per cent, as the analo
g
input can be switched as a
current or voltage input via switch S3.
Parameters Settings
No. Description Min. Max. Factory set-
ting
564 Point X1 -100,00 % 100,00 % -98,00 %
565 Point Y1 -100,00 % 100,00 % -100,00 %
566 Point X2 -100,00 % 100,00 % 98,00 %
567 Point Y2 -100,00 % 100,00 % 100,00 %
T
he coordinates of the points relate, as a percenta
g
e, to the analo
g
si
g
nal with 10 V
or 20 mA and parameter
Maximum Frequency 419 or parameter Maximum Reference
P
ercentage 519. The direction of rotation can be chan
g
ed via the di
g
ital inputs of the
frequency inverter and/or by selection of the points.
The definition of the analog input characteristic can be calculated via the two-point
form of the line equation. The speed Y of the drive is controlled ac-cording to the ana-
log control signal X.
()
Y1X1X
X1-X2
Y1-Y2
Y +−⋅=
Attention!
The monitoring of the analog input signal via parameter
Error/Warnin
g
behavior
563 demands examination of the characteristic parameters.
Sensible use is only possible if
Point X1 564 is in the positive range.
